Dispenser Setup
1. Turn on water source.
2. Open the pressure relief valve located on the front of the
unit, by ipping up on the valve cap lever. Hold open until
water ows from the relief valve then close (ip down) the
relief valve.
The dispenser must be properly electrically grounded
toavoidseriousinjuryorfatalelectricalshock.The
power cord has a three-prong grounded plug. If a
three-hole grounded electrical outlet is not available,
use an approved method to ground the unit. Follow all
localelectricalcodeswhenmakingconnections.Each
dispenser must have a separate electrical circuit. Do
not use extension cords. Do not connect multiple
electrical devices on the same outlet.
! WARNING
6. Test the motor operation by pushing the ice chute lever until
agitator motor begins to turn.
7. Activate each valve to ensure a good ow of water is
achieved.
8. Ensure pump deck is turned OFF before turning on CO
2
.
3. Verify all Bag-In-Box contains syrup and check all
connections for leaks.
4. Place enough ice in the ice bin to ll approximately 1/2 of the
bin before plugging in the unit.
5. Connect unit power cord to grounded electical outlet.
A. Pressure
Relief Valve
B. CO
2
Inlet
C. Valve Lever
A
B
C
9. Turn on CO
2
at the source then, using a screwdriver, adjust
the high pressure regulator at the source to 110 PSI (0.758
MPA) then tighten locknut with wrench.
 Thepumpdeckhasa3minutetimeoutfeature.Ifthe
 timeoutoccurs,turnthedeckOFFthenONbyipping
the switch on the control box.
NOTE
 TocheckforCO
2
leaks,closethevalveontheCO
2
cylinder and observe if the pressure to the system
 dropswiththecylindervalveclosedforveminutes.
 Openthecylindervalveaftercheck.
NOTE
14. Activate each valve to purge air from the syrup lines.
10. Adjust both of the low pressure regulators on the regulator
manifold to 75 PSI (0.517 MPA) then tighten locknut with
wrench.
11. Activate each valve until gas-out.
12. Plug in the remote carbonator pump deck, if not already
done so, and turn the switch to the ON position.
13. Activate each valve until the carbonator pump comes on.
Release the button, allow carbonator to ll and stop. Repeat
this process until a steady ow of carbonated water is
achieved.
A. Regulator Adjustment Screw
B. Adjust to 110 PSI (0.758 MPA)
C. Wrench
A
B
