lancer FS 30 - Counter Cutout

28
Counter Cutout
30”
28 1/8”
15/16”
30 1/2”
23”
18 5/8”
1 5/8”
7 1/2”
1 1/2”
3“ DIAMETER OPTIONAL
3“
26”
15”
11 1/2”
2“
FRONT OF DISPENSER
OPTIONAL HOLES FOR FASTENING DISPENSER TO COUNTER WITH SCREWS
CUT OUT DASHED AREA
FS30 COUNTER CUTOUT
DRIPTRAY
