4
SPECIFICATIONS AND FEATURES
• Units are equipped with an automatic agitation system and will activate unexpectedly.
• CAUTION: Do not place hands or foreign objects in the ice bin tank. Unplug the dispenser during servicing, cleaning, and
sanitizing.
• CAUTION: To avoid personal injury, do not attempt to lift the dispenser without assistance. For heavier dispensers, use a
mechanical lift.
! Automatic Agitation
Flavor Select (FS) 30”
This unit emits a sound pressure level below 70 dB
DIMENSIONS
Width: 30 inches (762 mm)
Depth: 30.5 inches (775 mm)
Height: 40.25 inches (1022
mm)
WEIGHT
Shipping: 356 lbs (161 kg)
Empty (without Ice): 320 lbs (145 kg)
Full (with Ice): 620 lbs (281 kg)
Ice Capacity: 290 lbs (132 kg)
Ice Dispensable: 215 lbs (98 kg)
ELECTRICAL
115 VAC / 60 Hz / 7.0 Amps
PLAIN WATER SUPPLY
Min Flowing Pressure: 75 PSIG
(0.516 MPA)
CARBONATED WATER SUPPLY
Min Flowing Pressure: 25 PSI
(0.172 MPA)
Max Static Pressure: 50 PSI
(0.345 MPA)
30”
(762 mm)
38 13/16”
(986 mm)
without lid
23”
(584 mm)
30 1/2”
(775 mm)
7 1/2”
(190 mm)
10”
(254 mm)
40 1/4”
(1022 mm)
with lid
5 1/2”
(140 mm)
4 1/2”
(114 mm)
14 5/8”
(372 mm)
CARBON DIOXIDE (CO
2
)
SUPPLY
Min Pressure: 70 PSIG (0.483 MPA)
Max Pressure: 80 PSIG (0.552 MPA)
FITTINGS
Carbonator Inlet: 3/8 in barb
Plain Water Inlet: 3/8 in barb
Brand Syrup Inlets: 3/8 in barb
Flavor Injector Inlets: 1/4 in barb
CO
2
Inlet: 3/8 in barb
To Next Page
