lancer FS 30 - Lancer Flow Control Valve (LFCV)

26
8
7
5
4
3
2
Spare Parts
Valve Assembly
1
6
8
7
5
4
3
2
Spare Parts
Valve Assembly
1
6
LFCV VALVE ASSEMBLIES:
Item Description
82-3820 LFCV, BONUS INJECTOR
82-3823 LFCV, 3.0 - 4.5, SYRUP ASSY
82-3824 LFCV, 3.0 - 4.5, SODA/WATER ASSY
LFCV KIT:
82-4020/01 LFCV REBUILD KIT
LFCV SPARE PARTS:
Item Part No. Description
1 10-0870/01 PLUG NUT,SOLENOID, 2PK
2 02-0538 O-RING
3 12-0364/04-01 COIL, LFCV
4 23-1442/01 CORE ASSY,SIMRIT COMPOUND C
5 03-0180/02 SPRING, CORE
6 02-0109 O-RING
7 05-1745/02 SEAT, LFCV
8 02-0133 O-RING
Lancer Flow Control Valve (LFCV)
