23
Part No. Description
85-14808-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 8 brands / 12 avors
85-14810-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 10 brands / 12 avors
85-14812-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 12 brands / 12 avors
85-14814-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 14 brands / 12 avors
85-14816-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 16 brands / 12 avors
85-14808N-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 8 brands / 12 avors, Pellet
85-14810N-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 10 brands / 12 avors, Pellet
85-14812N-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 12 brands / 12 avors, Pellet
85-14814N-12 IBD, Above Counter Multi Brand Series 14800, 115V/60Hz, 14 brands / 12 avors, Pellet
Item Part No. Description
1 82-4183 Drip Tray Assy,30
2 30-8364/01 Splash Plate
3 30-6147 Cover, Motor, IBD
4 82-3688 Motor Assy
- 91-0165/01 Motor, Agitator, IBD
5 82-3196 Motor Assy, Carbonator
- 86-0084-SP Pump Assy
- 91-0063 Motor, Carbonator
6 17-0611 Check Valve, Vented, 5/8 x 18
7 01-2214 Nut, Swivel, Probe, Carb
8 52-2751/02 Body, Probe, Sub Assy, Carb
9 82-3370/02 CO
2
Assy, Inlet/P-OFF
- 54-0066 Relief Valve Assy
10 54-0289 Nozzle Assy, Multi-Flavor, STHL
- 05-1855/01 Nozzle, Multiavor
- 02-0231 O-ring
11 05-2120 Bezel, Multi-Brand, 1L/2R
- 05-2121 Bezel, Multi-Brand, 2L/1R
- 05-2122 Bezel, Multi-Brand, 1L/1R
- 05-2058 Bezel, Multi-Brand, 2L/2R
12 82-3286/02 Switch Assy, MB, 2L/2R
13 82-3820 Valve Assy, LFCV, 0.2, Syrup
Injection, Natural
14 82-3824 Valve Assy, LFCV, 4.5, Soda/Water,
Gray
15 82-3823 Valve Assy, LFCV, 4.5, Syrup, Black
16 04-1089 Screw, 10 - 32 x 1.000, RH, PH/SL
17 82-2317/01 Block Mounting Assy, SGL
18 82-4372 Kit, Controller Board,FS30
19 02-0406/01 Seal, Shaft, Motor, IBD
20 82-3556 Dispensing Wheel, HEX, IBD
21 23-1373 Agitator Assy, HEX
22 10-0762 Pin, Agitator, 1/4”, PASS
23 03-0368 Retainer, RUE-14-S
24 05-1555 Bearing, Agitator, Rear, IBD
25 05-1606 Lid, Back, IBD30, Round
26 05-1476/01 Lid, Front, IBD, Round
27 05-1310/02 Shroud, Dispensing Wheel, Modied
28 82-3994/01 Reector Assy, FS30
- 12-0104/01 Indicator, LED Panel Mount
- 52-3133 Ballast Assy,230V,2 bulbs
29 12-0503 Bulb, Fluorescent, 26”, T8, CW
30 82-3705 Merchandiser Assy, FS - No graphic
31 52-3433 Harness,Valve,25-PIN,FS/ADA
32 52-2692/01 Harness, Control-to-Valve, 9-PIN
33 82-3284 Power Supply
34 30-8871/02 Cover, power Supply
35 82-3987 Ice Chute Assy, Mercury
ICE DOOR SOLENOID ASSEMBLY:
Item Part No. Description
A 03-0086 Ring, Retaining (5304-18)
B 04-0328 Washer, Rubber
C 04-0327 Washer, Flat
D 12-0195 Solenoid, D-90
E 30-5165 Bracket, Solenoid
F 23-1380 Plunger Assy
G 10-0496 Pin, Solenoid Assy
H 03-0110 Spring, Solenoid
I 03-0111 Ring, Retaining (5133-62)
J 30-8356 Linkage, Door, FS
