Table 6 Unit IN 2050 PW IN 2560 PW
Filling volume
‑ minimum L 11.1 12.1
‑ Maximum L 36.3 48.1
Pump data 50/60 Hz
‑ maximum discharge pressure bar 6.0 6.0
‑ Maximum flow rate l/min 120.0 100.0
Connector thread (outer) inlet/outlet mm M38 x 1.5 M38 x 1.5
Noise level 50 Hz Â
dB(A) 58 74
Noise level 60 Hz Â
dB(A) 58 74
Weight kg 382.0 647.0
Distance between device and environment
‑ Front mm 200 200
‑ Back mm 200 200
‑ Right mm 200 200
‑ Left mm 200 200
Class division according to DIN 12 876-1
‑ Class designation --- I I
‑ Identification code ---
NFL (suitable for
non-flammable liquids)
NFL (suitable for
non-flammable liquids)
À - ACC area (Active Cooling Control) according to DIN 12876 is the
working temperature range during operation with an active cooling unit.
Á - Temperature stability determined according to standard DIN 12876-2
 - Noise level determined according to standard EN 11201 for operating
position in front of the device at 1 meter distance
15.2 Heating output and power supply
If the maximum current consumption is limited Ä “Limiting the current
consumption” on page 101 the heating output can be reduced.
Depending on the country-specific version, the maximum current con-
sumption may already be limited ex works. Limited current consumption
values are shown in brackets.
Table 1 Unit IN 130 T IN 230 T IN 230 TW
Heating output
230 V; 50 Hz kW 2.7 2.7 2.7
200 V; 50/60 Hz kW 2.2 2.2 2.2
Integral T
V6Integral Process Thermostats and High-Temperature Thermostats166 / 198
