Lauda IN 130 T - Pump characteristics for Integral T

Table 4 Unit IN 8 XTW
Heating output
‑ 400 V; 3/PE~50 Hz & 460 V;
3/PE~60 Hz
kW 8.0
Current consumption A 13.5
Subject to technical modifications!
15.6 Pump characteristics for Integral T
Fig. 92: IN 130 T, IN 230 T, IN 230 TW
Fig. 93: IN 530 T, IN 530 TW
measured with water for IN 130 T,
IN 230 T, IN 230 TW
measured with water for IN 530 T,
IN 530 TW
V6Integral Process Thermostats and High-Temperature Thermostats178 / 198
