ID Function Unit Command
28 Limitation of outflow temperature TiH (lower limit) [°C] OUT_SP_05_XXX
32 Temperature set point T
set
in Safe Mode [°C] OUT_SP_07_XXX.XX
Table 24: Pump
ID Function Unit Command
17 Pump power stage 1 – 8
(only for Integral XT)
[–] OUT_SP_01_XXX
30 Set pressure (for pressure control settings)
(only for Integral XT)
[bar] OUT_SP_06_X.XX
36 Through-flow control set point [l/min] OUT_SP_09_X.XX
70 Activate through-flow control: 0=Switch = switch o / 1 = switch on [–] OUT_MODE_05_X
155 Pressure limitation set point with active through-flow control
(MID flow controller must be connected and equipped with an inte-
grated pressure sensor)
[bar] OUT_SP_10_X.X
159 Actual value of external pressure control variable (via interface) [bar] OUT_PV_06_XX.XX
163 Pressure measurement value source [--] OUT_MODE_07_[value]
Table 25: Cooling
ID Function Unit Command
23 Cooling mode: 0 = o / 1 = on / 2 = automatic [–] OUT_SP_02_XXX
Table 26: Safety
ID Function Unit Command
34 Timeout communication via interface (1 – 60 seconds; 0 = O) [s] OUT_SP_08_XX
72 Activate Safe Mode [–] OUT_MODE_06_1
Table 27: Control parameters
ID Function Unit Command
38 Control parameter Xp [–] OUT_PAR_00_XX.X
40 Control parameter Tn (5 – 180 s; 181 = O) [s] OUT_PAR_01_XXX
42 Control parameter Tv [s] OUT_PAR_02_XXX
44 Control parameter Td [s] OUT_PAR_03_XX.X
46 Control parameter KpE [–] OUT_PAR_04_XX.XX
48 Control parameter TnE (0 – 9000 s; 9001 = O) [s] OUT_PAR_05_XXXX
50 Control parameter TvE (5 = O) [s] OUT_PAR_06_XXXX
V6 Integral Process Thermostats and High-Temperature Thermostats 59 / 198
