SMC6000 Series Motion Controller Hardware Installation Manual
9
HWMN-SMC6-R20120417
Table 2-5 Serial port COM1 pin assignment (SMC6480, SMC6490 and PMC6496)
Serial Port COM1 Pin Assignment (SMC6480, SMC6490 and PMC6496)
Pin Name I/O Description
1
NC N/A Not connected
2
RXD0 I RS232 receive
3
TXD0 O RS232 transmit
4
NC N/A Not connected
5
EXGND GND External power ground
6 NC N/A Not connected
7
NC N/A Not connected
8
NC N/A Not connected
9
NC N/A Not connected
2.1.6. Serial Port COM2
COM2 is a D shell 9 pin female connector which has the transmitting and the receive pin for RS232 communication.
This port is used for controller configuration or downloading/downloading motion program. See table 2-6 for the
detail.
Table 2-6 Serial port COM2 Pin assignment (SMC6480, SMC6490 and PMC6496)
Serial Port COM2 Pin Assignment (SMC6480, SMC6490 and PMC6496)
Pin Name I/O Description
1
NC N/A Not connected
2
RXD0 I RS232 receive
3
TXD0 O RS232 transmit
4
NC N/A Not connected
5
EXGND GND External power ground
6
NC N/A Not connected
7
NC N/A Not connected
8
NC N/A Not connected
9
NC N/A Not connected
2.1.7. Power-up level DIP Switch Function
There is a 4 bit DIP switch for setting of power-up level for digital outputs 1-24. See table 2-7 for the detail.
