Chapter 5 Mechanical Specifications
5.1 Mechanical Specification of SMC6480
78
203.5
118
5
4-R3
Figure 5-1: Mechanical Specification of SMC6480
5.1 Mechanical Specification of SMC6490 and SMC64596
Figure 5-2: Mechanical Specification of SMC6490 and PMC6496
