SMC6000 Series Motion Controller Hardware Installation Manual
2
HWMN-SMC6-R20120417
1.2 Product Covered
This manual tries to specify the functionality, structure, connector pin assignment and connections of Leadshine
SMC6480, SMC6490 and PMC6496. Table 1-1 illustrates the key features of Leadhine SMC600.
Table 1-1 SMC6000 Motion Controller Specifications
SMC6480 SMC6490 PMC6496
Number of Controllable Axes 4 4 4
Pulse Output Frequency( MAX)
5.0MHz 5.0MHz 5.0MHz
Position Range -2,147,483,647 to +2,147,483,648 (32 BIT)
Interpolation Cycle 300 us 300 us 300 us
General Purpose
Digital Inputs
24 inputs include 8 isolated inputs and 16 non-isolated inputs
General Purpose
Digital Outputs
32 inputs include 16 isolated inputs and 16 non-isolated inputs
D/A Outputs 2 Channels, 0.07~4.45V, 8 bit
- -
Encoder Counter - 4 Channels, Max 4 MHz bandwidth, 32 bit counter
Manual Pulse Input 1 Channel, Max 1MHz bandwidth
PWM Output 2 Channels, Max 1MHz bandwidth, duty-cycle 0~100%, 32-bit resolution
Flash Memory 32M Bytes 32M Bytes 8M Bytes
Ferroelectric Memory - 32K Byte Optional 32K Bytes
Network Interface 10M/100M Ethernet
Serial Port RS-232, 2 D-Shell 9-pin connector
USB Disk Interface USB 1.1, 12Mbytes / s
External Power Supply 24VDC, 1100mA
Operating Temperature 0~50℃ 0~50℃ 0~50℃
Storage Temperature -20~80℃ -20~80℃ -20~80℃
Size 208mm*116mm*42mm 186mm*147mm*42mm
Programming G Code, BASIC, VB/VC library
1.3 Applications
• Electronic assembly and measurement equipments
• Semiconductor and LCD manufacturing & measurement equipments
• Laser cutting/engraving/marking equipments
• Vision & measurement automation equipments
• Biotech sampling and handing devices
• Robotics
• Special CNC machines
• Other automation system using stepper and servo
