176
28
295
REF.
56
typ
28
52
28
114
430
mm BETWEEN MOUNTING SCREWS
B
B
M6 EARTHING SCREW
ALARMS TO ESD SYSTEM
3 OR 4 SENSOR INPUTS
(INTERMEDIATE JB)
TO HOOTER & BEACON
BB
EARTHING
Exde PUSHBUTTONS
SPARE
180
GLASS WINDOW,
FRONT PANEL BENEATH
632
432
457
11
TYP
FOR MOUNTING SCREW
175 80
x80
550
SS316
TAG
(100x100mm)
Tag text per
customer request
M4, 10mm
deep(x4)
COVER HINGE (x2)
NOTES:
* THREADS SUPPLIED WITHOUT CABLE ENTRIES.
* ALL THREADS ARE CLOSED WITH CERTIFIED PLUGS.
A=M32x1.5 (x2)
B= M20x1.5 (x11)
C= M25x1.5 (x2)
D=M4,10mm deep (x4)
*SEALING: IP66
*ENCLOSURE MATERIAL: COPPER FREE ALUMINIUM ALLOY.
*PAINT: EPOXY COATING RAL 7035.
A
A
C
C
BB
POWER
UNIT 1: TAG N0. 433-LCP-001A
UNIT 2: TAG N0. 433-LCP-001B
B
B
BBB
DD
D
D
D
ENCLOUSUR:
FINISH:
DATE
DRAWING NUMBER:
CSLC0150-D
1:10
SCALE:
SHEET
OF
1 1
TITLE:
SLC-220 MULTI
EExd IIB ENCLOSURE
SIZE
A3
WT.
QT.:
2
DD/MM/YY
TREATMENT:
.
EJB-5B/1W3 (CORTEM)
TOLERANCES UNLESS
OTHERWISE SPECIFIED
LINEAR
ANGULAR
SURFACE FINISH
BREAKEDGES
0.2
1
N7
0.2x45
DATE
NAME
DESIGN
DRAWN
CHECK
APPROV
H. K.
H. K.
H. K.
H. K.
17/08/2015
17/08/2015
17/08/2015
17/08/2015
USED ON:
SLC-220/EExd
DESCRIPTION
DATE
APPR BY
REV
DD/MM/YY
H. K.
ECR. No.
GE
Water & Process Technologies
Analytical Instruments
PROJECT: ZADCO TANK 7.
