34
Instructions for Use V 1.9 RevC - 06/2013
• Carefullypushinthebladefromaboveorfrom
the side. Make sure that the blade is clamped
in the center and, most importantly, parallel to
the upper edge of the pressure plate.
• Toclamptheblade,rotateclampinglever(10)
clockwise back upwards.
Fig. 27
10
10
9a
9
• Toremovetheblade,foldtheclampinglever
(10) downwards counterclockwise.
The ejector (9a) ensures safe blade changing.
Once the blade has been removed from the blade
holder, it is disposed of into the dispenser con-
tainer (underside, see image).
• Anotheroptionforremovingthebladeistouse
the brush with magnet.
To do so, fold the clamping lever (10) down-
wards counterclockwise. Likewise, fold the
knife guard (9) downward. Guide the brush
with magnet to the blade and lift it upwards
and out.
9
5. Operation
Use the blade ejector to eject the
blade!
