Leica RM2245 - 7 Troubleshooting; Instrument Malfunctions; Error Reports

62
Instructions for Use V 1.9 RevC - 06/2013
7. Troubleshooting
7.1.1 Error reports
Indication E1
If this message follows the software version indication after switching on
the instrument, a loss of all parameters has occurred.
• Pressanykey.
All parameters are then set back to the default values.
• Nowallsettingsmustbecheckedtoseeifthepreviouslyenteredvalues
are still correct.
The values may have to be reentered.
Youcancontinuewithyournormalworkingroutine.
If E-1 appears repeatedly when switching the instrument on, the lithium
battery may need replacement (service life approx. 7 years).
• Proceedasdescribedabove.
• Worknormallyaftercheckingthesettings.
• HavethebatteryreplacedbyLeicaserviceassoonaspossible.
LEDs (40), (41) in the coarse feed buttons are lit at the same time.
This indicates a defect in the detection of the STOP and HOME positions of
the specimen head.
The problem can only be resolved by customer service.
7.1 Instrument malfunctions
40
41
Certain instrument malfunctions appear on the 3-digit LED display or are indicated
through illuminated LED's on the control panel.
