Leica RM2245
6.1.4 Quick clamping system
It is used as a specimen holder for use with the
fine-directional specimen holder fixture with
zero point indicators or the directional specimen
holder fixture.
• Screwthe4screws(13) into bore A with an
Allen key No. 2.5 and tighten them.
13
A
A
6. Optional Accessories
Fig. 31
