32 680 Series Video Distribution Amplifiers Installation and Operation Manual
Chapter 8: Specifications
Frame Specifications
FR-683 Mounting Frame
FR-684/FR-684AV Mounting Frames
Table 8-1. FR-683 Electrical Specifications
Item Specification
Voltage 90–135 VAC (684PS–120V)
190–265 VAC (684PS–240V)
Frequency 50/60 Hz
Power 50 VA max. (fully loaded)
Table 8-2. FR-683/FR-683AV Mechanical Specifications
Item Specification
Height 1¾ in. (44 mm)
Width 19 in. (483 mm)
Depth from mounting surface 12½ in. (317 mm)
Nominal weight (with modules) 12.7 lb (5.8 kg)
Table 8-3. FR-684/FR-684AV Electrical Specifications
Item Specification
Voltage 90–135 VAC (684PS–120V)
190–265 VAC (684PS–240V)
Frequency 50/60 Hz
Power 50 VA max. (fully loaded)
Table 8-4. FR-684/FR-684AV Mechanical Specifications
Item Specification
Height 3½ in. (44 mm)
Width 19 in. (483 mm)
Depth from mounting surface 12½ in. (317 mm)
Nominal weight (with modules) 16 lb (7.3 kg)
