40 680 Series Video Distribution Amplifiers Installation and Operation Manual
Chapter 8: Specifications
Table 8-35. VEH-683 Output Specifications
Item Specification
Output number 8
Output impedance 75Ω
Output return loss 45 dB/5 MHz
35 dB/20 MHz
25 dB/100 MHz
Maximum output level 2.6 Vp-p
Output isolation 45 dB/5 MHz
Output delay match ±0.3°
