5.4303.8558.0 -
Maintenance 7-9
9. Tap Driven distance.
10. Fill out the driven distance in mm.
11. Tap button Calibrate.
12. Calibration of wheel diameter was successfull is displayed.
13. Tap Ok.
14. Examine the wheel calibration values and the date of calibration. If necessary, repeat the calibration
procedure.
Close-up
1. Drive the machine to the charging station.
2. Put the machine into operation.
7.3.9 Test the Emergency Stop Button
While the machine is in operation and drives a route:
1. Push the emergency stop button. The machine must stop immediately.
2. Pull the emergency stop button upwards.
3. On the smartphone display tap Mark as solved. The alarm list is displayed.
4. Tap
to go to the home screen.
5. Examine if the user interface indicates to:
1. Release the emergency stop button.
2. Press the pause button.
3. Put the machine into operation (tap start in the user interface).
6. Make sure the status lights of the motors are green.
7. Tap
on the smartphone or the pause button on the machine. The machine continues operation.
7.3.10 Examine and replace the metal Strips
Sharp, protruding object.
Risk of falling, being cut or damage to the machine.
Make sure the metal strips are properly attached to the floor and do not
point upwards at one side.
in n o vato rs in agriculture
