Lennox PRODIGY M2 User Manual

17. Electronic Configure To Order (ECTO) Control Parameters
Page 84
506457−01 05/10
Control Parameter
No. Name
DescriptionUnits
Control Value
Min. Default Max.
Block 9 Optional A133 Board in GP Mode (DIP switch set to GP) Parameters (continued)
9.08
AO1_PID_
ManRS
0
0
50
50
100
100
Counts
P:%
Analog output channel 1 PID loop manual reset value.
9.09
AO1_PID_P_
Constant
0 0 127 Counts Analog output channel 1 PID loop proportional constant.
9.10
AO1_PID_I_
Constant
0 0 127 Counts Analog output channel 1 PID loop integral constant.
9.11
AO1_PID_D_
Constant
0 0 127 Counts Analog output channel 1 PID loop derivative constant.
9.12
AO2_Control_
Mode
0 0 11 Option
Analog output channel 2 control mode.
0 − No operation. Analog Output 2 off.
Enabled When Control
1− Occupied PID setpoint A
Unoccupied PID setpoint B
2− Occupied PID setpoint A
Unoccupied Staged output B
3− Occupied Staged output A
Unoccupied PID setpoint B
4− Occupied Staged output A
Unoccupied Staged output B
5− Blower On PID setpoint A
Blower Off PID setpoint B
6− Blower On PID setpoint A
Blower Off Staged output B
7− Blower On Staged output A
Blower Off PID setpoint B
8− Blower On Staged output A
Blower Off Staged output B
9− DI2 (A133_P194−2) on PID setpoint B(1)
DI1 (A133_P194−1) on PID setpoint A(2)
Otherwise off
10− DI2 (A133_P194−2) on PID setpoint B (1)
DI1 (A133_P194−1) on Staged output A (2)
Otherwise off
11− DI2 (A133_P194−2) on Staged output B(1)
DI1 (A133_P194−1) on Staged output A (2)
Otherwise off
(1)−DI1 (A133_P194−2) doesn’t matter.
(2)−DI2 (A133_P194−1) is off
9.13 AO2_SP_A
0
0
−0.5
0
127
5.00
0
2.5
255
10.0
0.5
5.0
Counts
R:Volts
M:"w.c.
N:"w.c.
Analog output channel 2 setpoint A
Stg_Output_A 0 100 100 P:% Staged output A.
9.14
AO2_SP_B
0
0
−0.5
0
127
5.00
0
2.5
255
10.0
0.5
5.0
Counts
R:Volts
M:"w.c.
N:"w.c.
Analog output channel 2 setpoint B.
Stg_Output_B 0 100 100 P:% Staged output B.
9.15
AO2_Startup_
Value
0
0
50
50
100
100
Counts
P:%
Analog output channel 2 startup value. Value set to Analog Output
during the optional startup time delay set by ECTO 9.16.
9.16
AO2_Startup_
Delay
0
0
0
0
250
500
Counts
A:Sec.
Analog output channel 2 startup delay. Optional time delay before PID
loop starts.
9.17
AO2_Min_ Out-
put
0
0
20
20
100
100
Counts
P:%
Analog output channel 2 minimum output.
9.18
AO2_Max_ Out-
put
0
0
100
100
100
100
Counts
P:%
Analog output channel 2 maximum output.
9.19
AO2_PID_
ManRS
0
0
50
50
100
100
Counts
P:%
Analog output channel 2 PID loop manual reset value.
9.20
AO2_PID_P_
Constant
0 0 127 Counts Analog output channel 2 PID loop proportional constant.
9.21
AO2_PID_I_
Constant
0 0 127 Counts Analog output channel 2 PID loop integral constant.
9.22
AO2_PID_D_
Constant
0 0 127 Counts Analog output channel 2 PID loop derivative constant.
table continued on next page
