Lennox PRODIGY M2 User Manual

17. Electronic Configure To Order (ECTO) Control Parameters
Page 86
506457−01 05/10
Table 42. ECTO Parameter Code Conversion Table
Codes A Through F
A B C D E F
Counts
Sec. Min. Sec. Min. Sec. Min. Min. Hrs. Min.
0 0 0 0 0 0 0 0 0 0
10 20 0.33 40 0.67 80 1.33 5.33 0.36 2.67
20 40 0.67 80 1.33 160 2.67 10.67 0.71 5.33
30 60 1.00 120 2.00 240 4.00 16.00 1.07 8.00
40 80 1.33 160 2.67 320 5.33 21.33 1.42 10.67
50 100 1.67 200 3.33 400 6.67 26.67 1.78 13.33
60 120 2.00 240 4.00 480 8.00 32.00 2.13 16.00
70 140 2.33 280 4.67 560 9.33 37.33 2.49 18.67
80 160 2.67 320 5.33 640 10.67 42.67 2.84 21.33
90 180 3.00 360 6.00 720 12.00 48.00 3.20 24.00
100 200 3.33 400 6.67 800 13.33 53.33 3.56 26.67
110 220 3.67 440 7.33 880 14.67 58.67 3.91 29.33
120 240 4.00 480 8.00 960 16.00 64.00 4.27 32.00
130 260 4.33 520 8.67 1040 17.33 69.33 4.62 34.67
140 280 4.67 560 9.33 1120 18.67 74.67 4.98 37.33
150 300 5.00 600 10.00 1200 20.00 80.00 5.33 40.00
Codes I Through O
I J L M N O
Counts
CO
2
ppm mA Pres. "w.c. Pres. "w.c. Pres. "w.c. Differential Temp. F (C)
0 0 0 0 −0.5 0 0 (0.00)
10 78.43 0.78 0.04 −0.46 0.20 6.36 (3.53)
20 156.86 1.57 0.08 −0.42 0.39 12.72 (7.07)
30 235.29 2.35 0.12 −0.38 0.59 19.08 (10.60)
40 313.72 3.14 0.16 −0.34 0.78 25.44 (14.13)
50 392.15 3.92 0.20 −0.30 0.98 31.80 (17.67)
60 470.58 4.71 0.24 −0.26 1.18 38.16 (21.20)
70 549.01 5.49 0.27 −0.23 1.37 44.52 (24.73)
80 627.44 6.27 0.31 −0.19 1.57 50.88 (28.27)
90 705.87 7.06 0.35 −0.15 1.76 57.24 (31.80)
100 784.3 7.84 0.39 −0.11 1.96 63.60 (35.33)
110 862.73 8.63 0.43 −0.07 2.16 69.96 (38.87)
120 941.16 9.41 0.47 −0.03 2.35 76.32 (42.40)
130 1019.6 10.20 0.51 0.01 2.55 82.68 (45.93)
140 1098 10.98 0.55 0.05 2.75 89.04 (49.47)
150 1176.5 11.76 0.59 0.09 2.94 95.40 (53.00)
160 1254.9 12.55 0.63 0.13 3.14 101.76 (56.53)
170 1333.3 13.33 0.67 0.17 3.33 108.12 (60.07)
180 1411.7 14.12 0.71 0.21 3.53 114.48 (63.60)
190 1490.2 14.90 0.75 0.25 3.73 120.84 (67.13)
200 1568.6 15.69 0.78 0.28 3.92 127.20 (70.67)
210 1647 16.47 0.82 0.32 4.12 133.56 (74.20)
220 1725.5 17.25 0.86 0.36 4.31 139.92 (77.73)
230 1803.9 18.04 0.90 0.40 4.51 146.28 (81.27)
240 1882.3 18.82 0.94 0.44 4.71 152.64 (84.80)
250 1960.8 19.61 0.98 0.48 4.90 159.00 (88.33)
255 2000 20.00 1.00 0.50 5.00 162.18 (90.10)
