1.Pressthebluelatchtoopentheharddiskdrivetray1androtatethehandleoftheharddiskdrivetray
assemblytotheopenposition2).Then,graspthehandleandpulltheharddiskdrivetrayassembly
outofthebay3.
Figure24.Removingtheharddiskdrivetrayassembly
2.Removethefourretainingscrewsthatsecuretheharddiskdriveinthetray.Then,removethehard
diskdrive.
3.Ifyouareinstructedtoreturntheremovedharddiskdrive,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage68.
Installingahot-swapharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage17.
Thissectionprovidesinstructionsonhowtoinstallahot-swapharddiskdrive.Thissectionappliesonlyto
servermodelsthatsupporthot-swapharddiskdrives.
Attention:Tomaintainpropersystemcooling,donotoperatetheserverformorethan10minuteswithout
eitheradriveorallerpanelinstalledineachdrivebay.
Toinstallahot-swapharddiskdrive,dothefollowing:
Note:Youdonothavetoturnofftheserverfortheinstallationofahot-swapharddiskdrive.
1.Ifyouarereplacingahot-swapharddiskdrive,removetheoldonerst.See“Removingahot-swap
harddiskdrive”onpage32
.Ifyouareinstallingahot-swapharddiskdriveinablankbay,removethe
llerpanelforthebay.
2.Touchthestatic-protectivepackagethatcontainstheharddiskdrivetoanyunpaintedmetalsurface
ontheserver.Then,removetheharddiskdrivefromthepackage.
Note:Thehot-swapharddiskdriveserveroptionforRD240serverisafullyassembledtraywith
theharddiskdriveinstalledinthetray.
Chapter5.Installing,removing,orreplacinghardware33
