c.HoldthebatterycardassemblywiththebatterysideupandtheJ2board-to-boardconnectorlining
upwiththeJ7BBUconnector1ontheRAIDcontroller.Carefullypressthebatterycardassembly
ontotheRAIDcontrollersothatthetwoconnectorsarermlyjoined.Then,securethebattery
cardassemblytotheRAIDcontrollerwiththethreescrewsandthestandoffsthatcomewiththe
batterycardassemblyaccessorykit.
Figure34.Installingthebatterycardassembly
1J7BBUconnector
5.See“InstallingaPCIcard”onpage37andfollowthoseinstructionstoinstalltheRAIDcontroller.
44ThinkServerInstallationandUserGuide
