6.ConnecttheminiSASsignalcablestotheRAIDcontrollerandthebackplane.
Note:Usethetwo440mm(17.32inches)miniSASsignalcables.
Figure35.ConnectingtheminiSASsignalcables
1Ports0-3
2Ports4-7
a.ForoneminiSASsignalcable,connectoneendtotheports0-3ontheRAIDcontroller.Then,
connecttheotherendtotheminiSASsignalconnector
2onthebackplane.
b.FortheotherminiSASsignalcable,connectoneendtotheports4-7ontheRAIDcontroller.Then,
connecttheotherendtotheminiSASsignalconnector1onthebackplane.
Figure36.MiniSASsignalconnectorsonthebackplane
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage68
.
Chapter5.Installing,removing,orreplacinghardware45
