ToinstallthebatterycardassemblyontotheRAIDcontroller,dothefollowing:
a.Notethetopviewandbottomviewofthebatterycardassembly.Then,insertthebatterypack
harnessconnectorintotheJ4batterypackharnessconnectoronthebacksideofthebatterycard
assembly.Formoreinformation,refertothefollowingillustrations.
Figure37.Topviewofthebatterycardassembly
1Batterypackharness
Figure38.Bottomviewofthebatterycardassembly
1J4batterypackharnessconnector
2J5board-to-boardconnector
3J2connector
b.Withthefrontsideup,placetheRAIDcontrolleronaat,clean,static-freesurface.
Chapter5.Installing,removing,orreplacinghardware47
