c.HoldthebatterycardassemblywiththebatterysideupandtheJ5board-to-boardconnector
liningupwiththeJ10BBUconnector1ontheRAIDcontroller.Carefullypressthebatterycard
assemblyontotheRAIDcontrollersothatthetwoconnectorsarermlyjoined.Then,securethe
batterycardassemblytotheRAIDcontrollerwiththethreescrewsandthestandoffsthatcome
withthebatterycardassemblyaccessorykit.
Figure39.InstallingthebatterycardassemblyontotheRAIDcontroller
1J10BBUconnector
6.ConnectoneendoftheminiSASsignalcabletotheRAIDcontroller.
Note:Usethetwo400mm(15.75inches)miniSASsignalcables.
Figure40.ConnectingtheminiSASsignalcablestotheRAIDcontroller
1Ports0-3
2Ports4-7
a.ForoneminiSASsignalcable,connecttheendtotheports0-3ontheRAIDcontroller.
b.FortheotherminiSASsignalcable,connecttheendtotheports4-7ontheRAIDcontroller.
7.InstalltheRAIDcontrollerintoanappropriatePCIcardslotontherisercardassembly.Then,install
thescrewtosecuretheRAIDcontrollerinplace.
