Figure41.InstallingtheRAIDcontrollerintothePCIcardslotontherisercard
8.InstalltherisercardwiththeRAIDcontrollerintoanappropriatePCIcardslotonthesystemboard.
9.Connecttheotherendofthetwo400mm(15.75inches)miniSASsignalcablestothebackplaneof
yourserver.
Figure42.MiniSASsignalconnectorsonthebackplane
a.ForoneminiSASsignalcable,connecttheotherendtotheminiSASsignalconnector2onthe
backplane.
b.FortheotherSASsignalcable,connecttheotherendtotheminiSASsignalconnector1onthe
backplane.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage68.
Chapter5.Installing,removing,orreplacinghardware49
