Frontviewofservermodelswith2.5-inchharddiskdrives
Thefollowingillustrationshowsthefrontviewofservermodelswith2.5-inchharddiskdrives.
ID
6
CPU
MemPSU
Figure6.Frontviewofservermodelswith2.5-inchharddiskdrives
1Frontpanel52.5-inchharddiskdrivearea
2Pull-outinformationcard
6Slimopticaldrive(availableinsomemodels)
3IntelligentDiagnosticsModule
7Leftrackhandle
4Rightrackhandle
1Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage17.
2Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage13.
3IntelligentDiagnosticsModule
Formoreinformation,see“IntelligentDiagnosticsModule”onpage19.
4Rightrackhandle
7Leftrackhandle
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestoslidetheserveroutoftherack
cabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothattheserver
cannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRackInstallation
Instructionsthatcomeswithyourserver.
16ThinkServerRD330HardwareMaintenanceManual
