52.5-inchharddiskdrivearea
TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.The
numberoftheinstalledharddiskdrivesinyourservervariesbymodel.Thevacantharddiskdrivebaysare
occupiedbydummyharddiskdrivetrays.
Theharddiskdrivebaynumbersaremarkedonthetopedgeofthefrontbezel.
4
5
0
1
2
3
0
1
2
3
4
5
Figure7.2.5-inchharddiskdrivebaynumbers(topviewoftheserver)
6Slimopticaldrive
SomeservermodelscomewithaslimSATAopticaldrive.
Frontpanel
Thistopicprovidesinformationtohelpyoulocatethecontrols,connectors,andLEDsonthefrontpanelof
theserver.
Thefollowingillustrationshowsthecontrols,connectors,andLEDsonthefrontpaneloftheserver.
ID
Figure8.Frontpanel
1PowerswitchwithpowerstatusLED
5SystemerrorLED
2IDbuttonwithIDLED
6FrontUSBconnector1
3NetworkInterfaceController(NIC)1statusLED7FrontUSBconnector2
4NIC2statusLED8FrontVGADB-15connector
Note:ThefrontVGADB-15connectorisonlyavailableinservermodelswith2.5-inchharddiskdrives.
Chapter3.Productoverview17
