Lenovo ThinkServer RD330 - 2.7 RAID Availability

Thefollowingillustrationsshowtheconnectorsonthebackplanefor2.5-inchharddiskdrives.
Figure19.Frontviewofthebackplanefor2.5-inchharddiskdrives
1Slot0fora2.5-inchharddiskdrive4Slot5fora2.5-inchharddiskdrive
2Slot2fora2.5-inchharddiskdrive5Slot3fora2.5-inchharddiskdrive
3Slot4fora2.5-inchharddiskdrive6Slot1fora2.5-inchharddiskdrive
Figure20.Rearviewofthebackplanefor2.5-inchharddiskdrives
18-pinpowerconnector
3Mini-SASports0-3
2Mini-SASports4-54Opticaldrivepowerconnector
18-pinpowerconnector
Usedtoconnectapowercabletoprovidepowertothebackplane.
2Mini-SASports4-5
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive4toharddiskdrive5.
3Mini-SASports0-3
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.
4Opticaldrivepowerconnector
Usedtoconnectthepowercablefortheslimopticaldriveiftheserverhasoneinstalled.
Mini-SAStomini-SASsignalcableconnections
Thistopicprovidesinstructionsonthefollowingmini-SAStomini-SASsignalcableconnections:
•Connectingcablesfromthesystemboardtothebackplane
