Thefollowingillustrationsshowtheconnectorsonthebackplanefor3.5-inchharddiskdrives.
Figure17.Frontviewofthebackplanefor3.5-inchharddiskdrives
1Slot0fora3.5-inchharddiskdrive3Slot2fora3.5-inchharddiskdrive
2Slot1fora3.5-inchharddiskdrive4Slot3fora3.5-inchharddiskdrive
Figure18.Rearviewofthebackplanefor3.5-inchharddiskdrives
18-pinpowerconnector
3Mini-SASports0-3
2Opticaldrivepowerconnector
18-pinpowerconnector
Usedtoconnectapowercabletoprovidepowertothebackplane.
2Opticaldrivepowerconnector
Usedtoconnectthepowercablefortheslimopticaldriveiftheserverhasoneinstalled.
3Mini-SASports0-3
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.
Backplanefor2.5-inchharddiskdrives
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplanefor2.5-inchharddisk
drives.
Chapter3.Productoverview29
