•“InstallingorreplacingtheThinkServerRAIDSuperCapacitorModuleonthecoolingshroud”onpage166
•“InstallingorreplacingtheThinkServerRAIDSuperCapacitorModuleontherisercardassembly
2”onpage169
InstallingorreplacingtheThinkServerRAIDSuperCapacitorModuleonthecooling
shroud
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
•UseanydocumentationthatcomeswiththeThinkServerRAIDSuperCapacitorModuleandfollowthose
instructionsinadditiontotheinstructionsinthistopic.
ToinstallorreplacetheThinkServerRAIDSuperCapacitorModuleonthecoolingshroud,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaflat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.
3.Removetheservercover.See“Removingtheservercover”onpage89.
4.IfyouareinstallingtheThinkServerRAIDSuperCapacitorModule,gotostep5.
IfyouarereplacingtheThinkServerRAIDSuperCapacitorModule,dothefollowing:
a.DisconnectthecableoftheThinkServerRAIDSuperCapacitorModulefromthePCIExpresscard.
Pressthetab1slightlyoutwardtoensurethatitcansmoothlypassthroughtheholeinthebracket
whenyouliftthebracket.Then,removethebracketwiththeThinkServerRAIDSuperCapacitor
Moduleasshown.
Figure122.RemovingtheThinkServerRAIDSuperCapacitorModulewiththebracketfromthecoolingshroud
166ThinkServerRD440UserGuideandHardwareMaintenanceManual
