b.Gentlypressthetab1onthebracketandremovetheThinkServerRAIDSuperCapacitorModule
fromthebracketatthesametime.
Figure123.RemovingtheThinkServerRAIDSuperCapacitorModulefromthebracket
5.Touchthestatic-protectivepackagethatcontainsthenewThinkServerRAIDSuperCapacitorModule
toanyunpaintedsurfaceontheoutsideoftheserver.Then,takethenewThinkServerRAIDSuper
CapacitorModuleoutofthepackage.
6.NotetheorientationofthenewThinkServerRAIDSuperCapacitorModule.Then,gentlypressthetab
1onthebracketandinstallthenewThinkServerRAIDSuperCapacitorModuleintothebracketat
thesametime.
Figure124.InstallingtheThinkServerRAIDSuperCapacitorModuleintothebracket
Chapter6.Installing,removing,orreplacinghardware167
