3Pull-outinformationcard
Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage14.
4Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage22.
5Diagnosticpanel
Thediagnosticpanelvariesbymodel.Fordetailedinformation,see“Diagnosticmodule”onpage24.
6Slimopticaldrive
SomeservermodelscomewithaslimSATAopticaldrive.
Frontviewofservermodelswithtwelve3.5-inchhard-disk-drivebays
Thefollowingillustrationshowsthefrontviewofservermodelswithtwelve3.5-inchhard-disk-drivebays.
Figure7.Frontviewofservermodelswithtwelve3.5-inchhard-disk-drivebays
13.5-inchhard-disk-drivearea
6NetworkInterfaceController(NIC)1statusLED
2Rackhandle(left)7NIC2statusLED
3FrontUSBconnectors(2)8SystemerrorLED
4PowerbuttonwithpowerstatusLED
9Rackhandle(right)
5Systemidentificationbutton(IDbutton)withIDLED
18ThinkServerRD440UserGuideandHardwareMaintenanceManual
