13.5-inchhard-disk-drivearea
TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.
Thenumberoftheinstalledharddiskdrivesinyourservervariesbymodel.Thevacanthard-disk-drive
baysareoccupiedbydummyhard-disk-drivetrays.
Forservermodelswithtwelve3.5-inchhard-disk-drivebays,thehard-disk-drivebaynumbersaremarked
onthetopedgeofthefrontbezel.
Figure8.3.5-inchhard-disk-drivebaynumbers(topviewoftheserver)
2Rackhandle(left)
9Rackhandle(right)
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserverout
oftherackcabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothat
theservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.
Forservermodelswithtwelve3.5-inchhard-disk-drivebays,thefrontUSBconnectorsareintegratedinto
theleftrackhandle;andthefrontcontrolsandLEDsareintegratedintotherightrackhandle.
3FrontUSBconnectors
UsedtoattachaUSB-compatibledevice,suchasaUSBkeyboard,mouse,scanner,orprinter.Ifyou
havemorethansixUSBdevices,youcanpurchaseaUSBhub,whichyoucanusetoconnectadditional
USBdevices.
4PowerbuttonwithpowerstatusLED
Youcanpressthepowerbuttontoturnontheserverwhenyoufinishsettinguptheserver.Youalsocan
holdthepowerbuttonforseveralsecondstoturnofftheserverifyoucannotturnofftheserverfromthe
operatingsystem.SeeChapter4“Turningonandturningofftheserver”onpage63
.ThepowerstatusLED
helpsyoutodeterminethecurrentpowerstatus.
Chapter3.Productoverview19
