4PCIExpresscardareaforcardsontherisercardassembly1
TherearethreePCIExpresscardslotsontherisercardassembly1.
Figure18.Risercardassembly1
PCIExpresscardslot
Physicallink
width
Negotiablelinkwidth
Supportedcardlengthandheight
1
x8x4,x2,x1
Half-length,full-heightcard
2
x8x8,x4,x2,x1
Half-length,full-heightcard
3
x16x8,x4,x2,x1
Half-length,full-heightcard
Notes:
•ForaRAIDcard,itmustbeinstalledintotheslot3ontherisercardassembly1.Foranexpander
card,itmustbeinstalledintotheslot1ontherisercardassembly1.YoualsocaninstallaCNAcard
intoaPCIExpresscardslot.
•IfaThinkServerHBAisavailable,refertoitsuserguidefordetailedinformation.Theuserguideis
availablefordownloadat:
http://www.lenovo.com/UserManuals
32ThinkServerRD440UserGuideandHardwareMaintenanceManual
