Lenovo ThinkServer RS160 - Component Locations

RAIDconfigurationutilities
YourserversupportsonboardSATAsoftwareRAID.IfarequiredRAIDcardisinstalled,yourserveralso
supportsadvancedSATA/SAShardwareRAIDconfigurations.Formoreinformation,see“Configuring
RAID”onpage38
.
Remotemanagementsoftware
TheintegratedTMMprovidesbasicremotemanagementfeaturesfortheserver.
Formoreinformationabouttheremotemanagementsoftwareandserverremotemanagement,refertothe
ThinkServerManagementModuleUserGuide,whichisavailablefordownloadat:
http://www.lenovo.com/support
Componentlocations
Thistopicprovidesinformationtohelpyoulocateyourservercomponents.
Machinetype,model,andserialnumberlabel
WhenyoucontactLenovoforhelp,themachinetype,model,andserialnumberinformationhelpsservice
technicianstoidentifyyourserverandprovidefasterservice.
Locatethemachinetype,model,andserialnumberlabelontheserverasshowninthefollowingillustration.
!
ID
MT-M XXXX-XXX
S /N XXXXXXX
Figure1.Machinetype,model,andserialnumberlabel
Frontviewoftheserver
Thefrontviewoftheservervariesbymodel.Dependingonthemodel,yourservermightlookslightly
differentfromtheillustrationsinthistopic.
Figure2.Frontviewoftheserver
ItemDescription
1Frontpanel
See“Frontpanel”onpage12.
Chapter3.Productoverview11
