Systemboardcomponents
Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.
Figure18.Systemboardcomponents
1ManageabilityEngine(ME)recoveryjumpers
28-pinpowerconnector
324-pinpowerconnector4Memoryslots
5Systemfan1connector6Systemfan2connector
7Microprocessorsocket
8SATAconnectorforHDD0
9SATAconnectorforHDD1(upper)andSATAconnector
forHDD2(lower)
10SATAconnectorforODD(upper)andSATAconnector
forHDD3(lower)
11Frontpanelconnector112Frontpanelconnector2
13M.2SSDconnector14USB2.0connector
15Systemfan3connector
16TPMconnector
17Risercardassemblyslot
18ClearCMOSjumper
19Coin-cellbatterysocket
1MErecoveryjumpers
Usedtorecoverthemanageabilityengines.
28-pinpowerconnector
Usedtoconnectthe8-pinpowercableofthepowersupply.
324-pinpowerconnector
Usedtoconnectthe24-pinpowercableofthepowersupply.
Chapter3.Productoverview25
