LenovoThinkServerRAID520iPCIeAdapter
TheRAID520iAdapterprovidesadvancedSATA/SAShardwareRAIDfunctions.Thefollowingillustration
showstheconnectorsontheadapter.
Figure8.LenovoThinkServerRAID520iPCIeAdapter
Connector
Description
1Connector0Usedtoconnectthemini-SASsignalcable.
2Connector1Usedtoconnectthemini-SASsignalcable.
3J3connector
UsedtoconnecttoaThinkServerRAID520iupgradekey.
LenovoThinkServerRAID720iPCIeAdapter
TheRAID720iAdapterprovidesadvancedSATA/SAShardwareRAIDfunctions.Thefollowingillustration
showstheconnectorsontheadapter.
Figure9.ThinkServerRAID720iPCIeAdapter
Connector
Description
1Connector0Usedtoconnectthemini-SASsignalcable.
2Connector1Usedtoconnectthemini-SASsignalcable.
3ThunderboltFlash
Moduleconnector
UsedtoconnectaThunderboltMemoryModule.
18ThinkServerRS160UserGuideandHardwareMaintenanceManual
