Attention:
• Read “Safety inspection checklist” on page 43 and “Installation Guidelines” on page 41 to ensure that you
work safely.
• Touch the static-protective package that contains the component to any unpainted metal surface on the
server; then, remove it from the package and place it on a static-protective surface.
Notes:
• The PCIe adapter might look different from the illustration.
• Make sure to read and follow the documentation that comes with the PCIe adapter.
PCIe slot support
• PCIe slot 1: PCI Express 4.0 x16 (FHHL 75W PCIe adapter)
• PCIe slot 2: PCI Express 3.0 x1 (FHHL, 25W PCIe adapter)
• PCIe slot 3: PCI Express 3.0 x4 in x16 slot (FHHL, 25W PCIe adapter)
Notes:
• The RAID adapter should be installed in PCIe slot 1.
• Pentium processor supports up to PCI Express 3.0.
• When installing PCIe x8/x16 adapter to PCIe Slot 3, the PCIe adapter performance might be degraded
due to the bandwidth of PCIe slot 3 (x4).
• For a list of the supported PCIe adapters, see
https://static.lenovo.com/us/en/serverproven/index.shtml.
• The PCIe adapter might look different from the illustration.
• Make sure to read and follow the documentation that comes with the PCIe adapter.
Watch the procedure
A video of this procedure is available at YouTube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-
AU3iY3F7lq3qfqr5caGbIu
.
About this task
Step 1. If a bracket is installed in the chassis, open the PCIe adapter retainer bracket and remove the
bracket from the chassis. Keep the bracket for future use.
Chapter 3. Server hardware setup 87
