Lenze 8200 vector - Page 149

7
Commissioning
The most important codes for commissioning
EDK82EV113 DE/EN/FR 8.1
L
148
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0034*

(A)
uSEr
Setpoint
selection range
Application I/O
Observe the jumper setting of the
function module!
1 X3/1U, X3/1I
0
0 Unipolar voltage 0 ... 5 V / 0 ... 10 V
2 X3/2U, X3/2I 1 Bipolar voltage −10 V ... +10 V Minimum output frequency (C0010)
not effective
2 Current 0 ... 20 mA
3 Current 4 ... 20 mA Changing the direction of rotation is
only possible with a digital signal.
4 Current 4 ... 20 mA open−circuit monitored Changing the direction of rotation is
only possible with a digital signal.
TRIP Sd5 if I < 4 mA
C0037 JOG1 20.00 −650.00 {0.02 Hz} 650.00
JOG = fixed setpoint
Additional fixed setpoints
ð C0440
C0038 JOG2 30.00 −650.00 {0.02 Hz} 650.00
C0039 JOG3 40.00 −650.00 {0.02 Hz} 650.00
C0087 Rated motor
speed
à
300 {1 rpm} 16000 àDepending on the controller
C0088 Rated motor
current
à
0.0 {0.1 A} 650.0 àDepending on the controller
0.0 ... 2.0 x rated output current of the
controller
C0089 Rated motor
frequency
50 10 {1 Hz} 960
C0090 Rated motor
voltage
à
50 {1 V} 500 à230 V with 230 V controllers,
400 V with 400 V controllers
C0091 Motor cos ϕ
à
0.40 {0.1} 1.0 àDepending on the controller
C0119

−35−
Configuration of
motor
temperature
monitoring (PTC
input) / earth
fault detection
0
0 PTC input not active
Earth fault detection
active
l Signal output configuration under
C0415
l If several parameter sets are used,
the monitoring must be separately
adjusted for each parameter set.
l Deactivate the earth fault
detection, if it has been activated
unintentionally.
l If the earth fault detection is active,
the motor starts after controller
enable with a delay of approx.40
ms.
1 PTC input active,
TRIP set
2 PTC input active,
Warning set
3 PTC input not active
Earth fault detection
inactive
4 PTC input active,
TRIP set
5 PTC input active,
Warning set
