8.2.1.2 Sengs in the Siemens »TIA Portal«
Here, commissioning with the Siemens »TIA Portal« is described. Please note
that in the default seng of the Siemens »TIA Portal« changes of network
parameters carried out by a Lenze engineering tool (e. g. »PLC Designer«) may
be overwrien.
1. Go to the device conguraon and open the net view to drag the controller from the
catalog to the net view of the PROFINET.
2. Assign the controller to the associated IO-Controller.
3. Mark the controller and change to the device view.
4. Set the IP address and the staon name ("PROFINET device name") in Properes.
See: 4Staon name and IP conguraon ^ 74
In order that the controller can be idened via Ethernet when the IO controller
is switched o, it is necessary that the staon name and the IP conguraon are
saved in the device with mains failure protecon via the separate entry with the
Lenze engineering tool. 40x2022:003
See: 4Saving the parameter sengs ^ 23
5. Below the device name and the name of the device descripon le, the device view shows
the pre-assignment of the output and input process data words.
In Slot 1, pre-assigned process data words can be changed.
6. Save the project in the engineering tool.
7. Load the conguraon into the IO-Controller.
8. Set the IO-Controller to RUN.
8.2.1.3 Device descripon le
The device descripon le must be installed in the engineering tool used for conguring the
network (e. g. Siemens »TIA Portal«).
•
Download of GSDML les
The name of the device descripon le is as follows:
"GSDML-V<x>.<zz>-Lenze-C<NNN>PN<Version>-<yyyy><mm><dd>.xml".
Wildcard Informaon
x Main version of the GSDML scheme used
zz One-digit or two-digit subversion of the GSDML scheme used
NNN Specicaon of the device designaon
Version First version of the soware that can be used with this GSDML.
yyyy Year of publicaon
in (mm) Month of publicaon
dd Day of publicaon
Dene the user data length
The conguraon is supported by 250 process data bytes (up to 244 slots and 1440 bytes of
max. IO data per direcon).
Example of selecng the device descripon le:
•
Mixed_In_Out_Byte_0008 8 process data bytes (In and Out direcon)
Conguring the network
PROFINET
Commissioning
73
