Lenze C520 - Default Chapter; Table of Contents

Contents
1 About this document 7
1.1 Document descripon 7
1.2 Further documents 7
1.3 Notaons and convenons 8
2 Safety instrucons 9
2.1 Basic safety instrucons 9
2.2 Applicaon as directed 9
2.3 Residual hazards 10
3 Product informaon 12
3.1 Idencaon of the products 12
3.2 Features 12
3.3 SD card 12
3.4 Backplane bus 13
3.5 Licence informaon 13
4 Mechanical installaon 14
4.1 Mounng the controller 14
5 Commissioning 15
5.1 Installaon of »PLC Designer« 15
5.2 Commissioning 15
5.3 Connect controller and Engineering PC 16
5.4 Set IP address on the PC 16
5.5 Start controller 17
5.6 Access to SD card 18
5.7 Create PLC program 19
5.8 Create task 20
5.9 Compile PLC program code 20
5.10 Establish connecon between controller and »PLC Designer« 20
5.11 Log in to the controller (load conguraon) 21
5.12 Parameterize controller 22
5.12.1 General informaon on parameter seng 22
5.12.1.1 Addressing of the parameters 22
5.12.1.2 Structure of the parameter descripons 22
5.12.2 Saving the parameter sengs 23
5.12.3 Reset parameters to default 23
5.13 Start PLC program 24
5.14 Generate boot applicaon 24
Contents
3
