8.2.6 Diagnoscs
8.2.6.1 LED status display
Notes on the connecon status with IO-Controller can be obtained via the LEDs "BUS RDY"
and "BUS ERR" of the PROFINET opon (front of the device).
In addion, the LEDs "Link" and "Acvity" at the RJ45 sockets indicate the connecon status to
the network.
LED "BUS RDY" (green)
Blinking paern State Meaning
O Not connected No connecon to the IO-Controller
Blinking
Connected IO-Controller in STOP
On
Data exchange IO-Controller in RUN (DATA_EXCHANGE)
LED "BUS ERR" (red)
Blinking paern State Meaning
O No fault No fault
ickers
IO-Device idenes
(localises)
The PROFINET funcon "node ashing test" is triggered by IO-Controller. The ickering
LED serves to idenfy (locate) an accessible IO-Device.
Blinking
Impermissible sengs Impermissible sengs: Stack, staon name or IP parameters are invalid.
On (red)
Fault Communicaon error (e. g. Ethernet cable removed)
LED "Link" (green)
Blinking paern Status/meaning
o No connecon to the network.
on
A physical connecon to the network is available.
LED "Acvity" (yellow)
Blinking paern Status/meaning
o No data transfer.
on or ickers
Data is exchanged via the network.
8.2.6.2 Informaon on the network
The following parameters show informaon on the network.
Parameter
Address Name / seng range / [default seng] Informaon
0x2382:001 Acve PROFINET sengs: IP address
•
Read only
Display of the acve IP address.
0x2382:002 Acve PROFINET sengs: Subnet
•
Read only
Display of the acve subnet mask.
0x2382:003 Acve PROFINET sengs: Gateway
•
Read only
Display of the gateway address.
0x2382:004 Acve PROFINET sengs: Staon name
•
Read only
Display of the acve staon name.
0x2382:005 Acve PROFINET sengs: MAC Address
•
Read only
Display of the acve MAC address.
