Lenze C520 - Dismount controller

10.1 Dismount controller
More informaon
For certain tasks, more informaon is available in addional documents.
Document Contents/topics
Conguraon document Basic informaon for ordering the product
Mounng instrucons Fundamental informaon on mounng the product
How to dismount the connected controller:
Precondion
•
The voltage supply of the enre system and the controller is switched o.
•
Supply connecons, bus connecons and all other connecons have been removed from
the controller.
•
The rst electronic module of the I/O system has been removed.
1. Remove the Controller.
2. Remove the SD card from the card slot.
The controller has been dismantled.
Mounng and dismounng of the controller
5
3
4
1
2
6
A
Replace controller
Dismount controller
