Codes
Important controller codes
10
l
106
EDS82ZAFPC201 EN 4.0
ƒ Transferring parameter sets with the keypad:
Selection Important
You can use the keypad to transfer parameter sets to other controllers.
During the transfer, access to the parameters via other channels will be inhibited!
Keypad ð controller
Overwrite all available parameter sets (PAR1 ... PAR4, FPAR1 if
available) with the corresponding keypad data
70 With function module
10 (other)
Keypad ð PAR1 (+ FPAR1)
Overwrite the selected parameter set and, if available, FPAR1
with the corresponding keypad data
71 With function module
11 (other)
Keypad ð PAR2 (+ FPAR1)
72 With function module
12 (other)
Keypad ð PAR3 (+ FPAR1)
73 With function module
13 (other)
Keypad ð PAR4 (+ FPAR1)
74 With function module
14 (other)
Controller ð keypad
Copy all available parameter sets (PAR1 ... PAR4, FPAR1 if
available) into the keypad
80 With function module
20 (other)
Keypad ð function module
Overwrite only the module−specific parameter set FPAR1 with
the keypad data
40 Only with function module
Function module ð keypad
Copy only the module−specific parameter set FPAR1 into the
keypad
50 Only with function module
ƒ Saving your own setting:
Selection Important
9 PAR1 ð own setting You can store your own setting for the controller parameters
(e.g. the delivery state of your machine):
1. Check that parameter set 1 is active
2. Inhibit the controller
3. Set C0003 = 3, confirm with v
4. Set C0002 = 9, confirm with v, your own setting has
been stored
5. Set C0003 = 1, confirm with v
6. Enable the controller
This function can also be used to copy PAR1 to the parameter
sets PAR2 ... PAR4
5 Own setting ðPAR1
Restore your own setting in the selected parameter set
6 Own setting ðPAR2
7 Own setting ðPAR3
8 Own setting ðPAR4
