Lenze E82ZAFPC201 - DRIVECOM Status Word

Process data transfer
DRIVECOM control
DRIVECOM status word
7
l
47
EDS82ZAFPC201 EN 4.0
7.2.3 DRIVECOM status word
Bit Meaning
0 Device status "Ready to switch on"
0
1
Status less than "Ready to switch on"
Status at least "Ready to switch on"
1 Device status "Switched on"
0
1
Status less than "Switched on"
Status at least "Switched on"
2 Device status "Operation enabled"
0
1
Status less than "Operation enabled"
Status "Operation enabled"
3 Device status "Fault"
0
1
No fault (TRIP)
Fault (TRIP) active
4 Status "Inhibit voltage" command
0
1
Command applied
Command not applied
5 Status "Quick stop (QSP)" command
0
1
Command applied
Command not applied
6 Device status "Switch−on inhibit"
0
1
Status "Switch−on inhibit" not active
Status "Switch−on inhibit" active
7 Collective warning
0
1
No warning
Warning (overtemperature) active
8 Collective message
Automatic setting and resetting of pulse inhibit (IMP) in the device status "Operation enabled".
Possible causes: Undervoltage, overvoltage or overcurrent
0
1
No message
Message IMP active
9 Bus access right
1 Always
10 Status speed/frequency deviation
0
1
RFG
on
tu RFG
off
RFG
on
= RFG
off
11
0
Status DRIVECOM speed limitation
Always
12 Mapping of FIF status word 1 (FIF−STAT1), bit 0 (DCTRL1−PAR−B0)
13 Mapping of FIF status word 2 (FIFSTAT2), bit 0 (DCTRL1−PAR−B1)
14 Mapping of FIF status word 1 (FIFSTAT1), bit 2 (MCTRL1−IMAX)
15 Mapping of FIF status word 1 (FIF−STAT1), bit 5 (PCTRL1−QMIN)
