Process data transfer
PROFIdrive control
PROFIdrive status word
7
l
52
EDS82ZAFPC201 EN 4.0
7.3.3 PROFIdrive status word
Bit Designation Description
0 Ready to switch on Device status information
0 = Status lower than "Ready to switch on"
1 = Status at least "Ready to switch on"
1 Ready for operation Device status information
0 = Status lower than "Ready for operation"
1 = Status at least "Ready for operation"
2 Operation enabled Device status information
0 = Status lower than "Operation enabled"
1 = Status "Operation enabled"
3 Fault (TRIP) Device status information
0 = No fault (TRIP)
1 = Fault (TRIP) active
4 OFF2 Information on command "OFF2"
0 = Command applied
1 = Command not applied
5 OFF3 Information on command "OFF3"
0 = Command applied
1 = Command not applied
6 Switch−on inhibit Device status information
0 = "Switch−on inhibit" status not active
1 = "Switch−on inhibit" status active
7 Warning Collective warning
0 = No warning
1 = Warning
8 Reserved Always 1
9 Master function
requested
1
10 SETPOINT−REACHED Status of the speed/frequency deviation
0 = RFG
on
<> RFG
off
1 = RFG
on
= RFG
off
11 Reserved 0
12 Manufacturer Mapping of FIF status word 1 (FIF−STAT1), bit 14 (DCTRL1−CCW)
13 Manufacturer Mapping of FIF status word 1 (FIF−STAT1), bit 15 (DCTRL1−RDY)
14 Manufacturer Mapping of FIF status word 1 (FIF−STAT1), bit 2 (MCTRL1−IMAX)
15 Manufacturer Mapping of FIF status word 1 (FIF−STAT1), bit 5 (PCTRL1−QMIN)
