Lenze E82ZAFPC201 - Telegram Structure

Parameter data transfer
PROFIdrive parameter data channel
PROFIdrive DP−V1
8
l
71
EDS82ZAFPC201 EN 4.0
8.2.2.3 Telegram structure
SD LE LEr SD DA SA FCS EDFC DSAP SSAP
DU
E82ZAFP015
Fig. 8−2 PROFIBUS data telegram with DP−V1
The data unit (DU) contains the DP−V1 header and the parameter request or the parameter
response.
In the following subchapters, the parameter request and the parameter response are
described in detail.
) Note!
The DP−V1 header consists of:
ƒ Function identifier
ƒ Slot number
ƒ Data set
ƒ Length of the user data
Please refer to the corresponding PROFIBUS specification for further
information on the DP−V1 header.
