14 Parameter reference
14.3 Parameters of the communication module for slot MXI2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14852
C14853
C14860
Parameter | Name:
C14852 | All words to standard device
Data type: UNSIGNED_16
Index: 9723 = 0x25FB
Display of the process data words 1 ... 32 that are transmitted from the communication module to the inverter.
Display range (min. value | unit | max. value)
0 65535
Subcodes Info
C14852/1
...
C14852/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14853 | All words from standard device
Data type: UNSIGNED_16
Index: 9722 = 0x25FA
Display of the process data words 1 ... 32 that are transmitted from the inverter to the communication module.
Display range (min. value | unit | max. value)
0 65535
Subcodes Info
C14853/1
...
C14853/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14860 | Settings
Data type: UNSIGNED_8
Index: 9715 = 0x25F3
From SW version 3.00 onwards
Display of current configuration data
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C13860/1 PROFIsafe
•0: not active
•1: active
C13860/2 Number of process data words
C13860/3 Reserved
C13860/4 Number of PROFIsafe words (0, 4 or 8 words)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
