Lenze Starttec E71MM402 - Page 68

2
Technical data
Rated data
EDK71MMXXX-020 DE/EN/FR 1.0
L
14
Rated control data
Features Terminal Specification
DC supply of control X3/59
Voltage +18 VDC ... +30 VDC
Current consumption 200 mA at 24 V (without load connected to
X3/20)
Internal DC supply X3/20 +18 VDC ... +30 VDC, max. 500 mA
Digital inputs X3/28
X3/E1 ... X3/E5
HIGH active
HIGH active
Level
LOW 0 ... +3 VDC
L
e
v
e
l
HIGH +12 VDC ... +30 VDC
Input resistance R
i
>4kΩ
Input current per input 8mAat24VDC
Digital outputs X3/A1 ... X3/A4 HIGH active
Level
LOW 0 ... +3 VDC
L
e
v
e
l
HIGH +12 VDC ... +30 VDC
Current load per output 200 mA at 24 VDC
Motor temperature monitoring X3/T1, X3/T2 PTC thermistor or thermostat (NC contact)
GND, reference potential X3/7
AS-interface X3/A+, X3/A- according to ASI specifica tion
